Description
| Turning diameter (Max.) | Ø230mm |
| Swing over cross slide | Ø135mm |
| Distance between centers | 550/750mm(optional) |
| Width of bed | 115mm |
| Spindle bore | Ø21mm |
| Spindle taper | MT3 |
| Spindle speed (9 steps) | 0~1800rpm |
| Top slide travel | 48mm |
| Cross slide travel | 125mm |
| Max. section of tools | 12x12mm |
| Range of metric threads | 0.5~3mm |
| Range of inch threads | 8~56T.P.I |
| Tailstock quill diameter | Ø26mm |
| Tailstock quill travel | 40mm |
| Taper of tailstock quill | MT2 |
| Motor power | 750w |
| Voltage | 110V~240V(1PH) |
| Packing size | 1055x565x575mm |
