Description
Lathe Machine BT360F:
Feature:
1. Hardened and ground bed guideways
2. Coolant equipment
3. Guaranteed true running accuracy of the spindle nose of better than 0.015 mm
4. Right-handed / left-handed rotation on the bed slide switchable via stem
5. Steady rest and follow rest
6. Halogen machine lamp
Feature:
1. Hardened and ground bed guideways
2. Coolant equipment
3. Guaranteed true running accuracy of the spindle nose of better than 0.015 mm
4. Right-handed / left-handed rotation on the bed slide switchable via stem
5. Steady rest and follow rest
6. Halogen machine lamp
7. Cover for leading spindle
|
Model |
BT360F |
|
Swing over bed |
356mm(14'') |
|
Swing over cross slide |
220mm(8-5/8'') |
|
Swing in gap diameter |
506mm(20'') |
|
Valid length of gap |
145mm(5-11/16'') |
|
Distance between centers |
750/1000mm(30/40'') |
|
Width of bed |
206mm(8'') |
|
Spindle nose |
D1-4 |
|
Spindle bore |
38mm(1-1/2'')or 51mm |
|
Taper of spindle bore |
MT NO.5 |
|
Range of spindle speed |
16changes,45-1800r/min |
|
Compound rest travel |
95mm(3-3/4'') |
|
Cross slide travel |
180mm(7'') |
|
Max.Section of tool |
16x16mm(5/8''x5/8'') |
|
Lead screw thread |
4mm or 8T.P.I |
|
Longitudinal feeds range |
0.0012''-0.0294''/rev(Inch lathe)or 0.043-0.653mm/rev(Metric lathe) |
|
Cross feeds range |
0.0004''-0.01''/rev(Inch lathe)or 0.027-0.413mm/rev(Metric lathe) |
|
Threads metric pitches |
0.45-7.5mm(Inch lathe)or 0.4-7mm(Metric lathe) |
|
Threads imperial pitches |
4-112T.P.I(Inch lathe)or 4-56T.P.I(Metric lathe) |
|
Tailstock diameter |
Ø45mm(1-3/4'') |
|
Tailstock travel |
120mm(4-3/4'') |
|
Tailstock taper |
MT No.3 |
|
Main motor power(double speeds) |
1.5/2.4KW(2/3HP) |
|
Coolant pump power |
0.04kw |
|
Overall dimension(LxWxH) |
182x74x125cm |
|
Packing size(LxWxH) |
193x76x158cm |
|
Net Weight |
730kg |
|
Gross Weight |
860kg |
|
Standard Accessories |
Optional Accessories |
|
1.Three- jaw chuck 2.Four-jaw chuck 3.Centers 4.Splash guard 5.Steady rest 6.Follow rest 7.Face plate 8.Coolant system 9.Foot brake 10.Toolbox&tool 1 set |
1.Driving plate 2.Living center 3.Taper turning attachment 4.Drill chuck 5.Stopper and localizer 6.Quick change tool post 7.Digital readout(2 axis/3 axis) 8.Chuck cover 9.Leadscrew cover 10.Tool post cover |
