Description
13mm Bench Type Drill Press
1. 1/2'' (13mm) Max.chuck Capacity
2. 210mm Swing
3. 5 Spindle Speeds
4. -45°-0°-+45° Table Tilt L&R
5. Optional Chuck Guard And Micro-switch For CE Requirement
Mini bench drill press ZJ4113:
|
Max Drilling Diameter |
Φ13mm(1/2'') |
|
Motor Power |
250/350w |
|
Chuck Capacity |
1.5-13mm |
|
Spindle Travel |
50mm |
|
Class Of Speed |
5 |
|
Speed50/60Hz |
620~2620/740~3140rpm |
|
Spindle Taper |
B16 |
|
Max distance from spindle axis to surface of column |
105mm |
|
Max distance from spindle end to surface of table |
220mm |
|
Max distance from spindle end to surface of base |
300mm |
|
Swing |
210mm |
|
Table Size |
160×160mm |
|
Base Size |
290×190mm |
|
Column Diameter |
Φ46mm |
|
Net Weight/ Gross Weight |
580mm |
|
Net Weight/ Gross Weight |
16/17kg |
|
Packing Size |
430×340×230mm |
|
Standard Accessories |
Optional Accessories |
|
1.Drill chuck 2.Wrench set 3.Aluminium motor |
1.Copper motor 2.Chuck guard with power off 3.Micro switch 4.Vice 5.Key less drill chuck 6.Laser light |
