HomeProductsDrilling MachineDrill PressFor metal ZJQ4116B Chinese bench drill press machine
  • For metal ZJQ4116B Chinese bench drill press machine
  • For metal ZJQ4116B Chinese bench drill press machine
  • For metal ZJQ4116B Chinese bench drill press machine
  • For metal ZJQ4116B Chinese bench drill press machine
For metal ZJQ4116B Chinese bench drill press machine For metal ZJQ4116B Chinese bench drill press machine For metal ZJQ4116B Chinese bench drill press machine For metal ZJQ4116B Chinese bench drill press machine

For metal ZJQ4116B Chinese bench drill press machine

  • Motor Power:375/450/550w
  • Chuck Capacity:3-16mm
  • Spindle Travel:60mm
  • Class Of Speed:12
  • drill press , chinese drill press , bench press drill
    Inquiry Send Email

    Description

    Model
    ZJQ4116B
    Max Drilling Diameter
    Φ16mm(5/8'')
    Motor Power
    375/450/550w
    Chuck Capacity
    3-16mm
    Spindle Travel
    60mm
    Class Of Speed
    12
    Speed50/60Hz
    300~2550/360~3060rpm
    Spindle Taper
    MT2
    Max distance from spindle axis to surface of column
    155mm
    Max distance from spindle end to surface of table
    490mm
    Max distance from spindle end to surface of base
    610mm
    Swing
    310mm
    Table Size
    Φ260mm
    Base Size
    420×250mm
    Column Diameter
    Φ58mm
    Height
    900mm
    Net Weight/ Gross Weight
    34/36kg
    Packing Size
    770×450×260mm

    Standard Accessories
    Optional Accessories
    1. Gear rim drill chuck(3-16mm)B16
    2. Morse taper MT2
    3. Wrench set
    4. Drill Chuck
    1. Keyless drill chuck
    2. Drill chuck guard
    3. Machine vice
    4. Front switch
    5. Micro switch
    6. Laser
    7. Machine lamp
