Description
| Model | ZJQ4116K |
|
Max Drilling Diameter |
Φ16mm(5/8’’) |
|
Motor Power |
375/450/550w |
|
Chuck Capacity |
3-16mm |
|
Spindle Travel |
60mm |
|
Class Of Speed |
5 |
|
Speed50/60Hz |
620~2620/740~3140rpm |
|
Spindle Taper |
B16 |
|
Max distance from spindle axis to surface of column |
130mm |
|
Max distance from spindle end to surface of table |
400mm |
|
Max distance from spindle end to surface of base |
515mm |
|
Swing |
260mm |
|
Table Size |
Ø250mm |
|
Base Size |
340×210mm |
|
Column Diameter |
Φ58mm |
|
Height |
840mm |
|
Net Weight/ Gross Weight |
30/32kg |
|
Packing Size |
665×415×260mm |
|
Standard Accessories |
Optional Accessories |
|
1.Gear rim drill chuck(3-16mm)B16 2.Morse taper |
1.Keyless drill chuck 2.Drill chuck guard 3.Machine vice 4.Front switch 5.Laser 6.Machine lamp |
