Description
| Max.drilling capacity | 40mm |
| Max. Tapping diameter | M28 |
| Spindle taper | MT4 |
| Spindle stroke | 180mm |
| Spindle center to column surface | 360mm |
| Spindle nose to worktable | 600mm |
| Spindle nose to base | 1215mm |
| Spindle speeds range (12steps) | 42~2050rpm |
| Speed power feed range (4steps) | 0.07/0.15/0.26/0.4mm/r |
| Diameter of column | 160mm |
| Worktable size | 370x500mm |
| Base size | 460x450mm |
| Width of T-slot | 2-14mm |
| Main motor | 2.2/2.8kw (double speed) |
| Packing size | 2200x700x1150 |
| N.W/G.W | 640/750kg |
