Description
| Max.drilling capacity | 40mm |
| Max. Tapping diameter | M24 |
| Spindle taper | MT4 |
| Spindle stroke | 180mm |
| Spindle center to column surface | 350mm |
| Spindle nose to worktable | 770mm |
| Spindle nose to base | 1215mm |
| Spindle speeds range (12steps) | 50~1450rpm |
| Speed power feed range | 0.1/0.2mm/r |
| Diameter of column | 150mm |
| Worktable size | 560x560mm |
| Base size | 735x510mm |
| Width of T-slot | 4-18mm |
| Main motor（2 speed motor） | 1.1/1.5kw |
| Packing size | 2270x580x1100mm |
| N.W/G.W | 540/600kg |
