Description
|
Modle |
BT660 |
|
Max.swing over bed |
Ø 660mm(26'') |
|
Max.swing over cross slide |
Ø 440mm(17'') |
|
Max.swing over gap |
Ø 900mm(34'') |
|
Valid length of gap |
250mm |
|
Distance between center |
1000/1500/2000/3000mm |
|
Width of bed |
400mm |
|
Spindle hole |
Ø 105mm |
|
Net weight |
3150/3450/3750/4250kg |
|
Gross weight |
3350/3700/4050/4650kg |
|
Packing size |
(2680/3180/3680/4680) x 1130 x 2000mm |
|
Standard Accessories |
Optional Accessories |
|
1. Dead centers 2. Foot brake 3. Steady rest 4. Follow rest 5. Face plate 6. Change gears 7. Coolant system 8. Splash guard 9. Toolbox&tool 1 set 10. 3- jaw chuck(320mm) 11. 4- jaw chuck(400mm) |
1. Drill chuck 2. Driving plate 3. Living center 4. Tool post cover 5. Leadscrew cover 6. Stopper and localizer 7. Quick change tool post 8. 2-axis Digital readout 9. 3-axis Digital readout 10. Taper turning attachment 11. Chuck guard |
