Description
| Turning diameter (Max.) | Ø250mm |
| Swing over cross slide | Ø140mm |
| Distance between centers | 550/750mm (Optional) |
| Width of bed | 135mm |
| Spindle bore | Ø21mm |
| Spindle taper | MT3 |
| Variable speed | 100~2200rpm |
| Top slide travel | 70mm |
| Cross slide travel | 120mm |
| Max. section of tools | 12x12mm |
| Range of metric threads | 0.125~2.5mm |
| Range of inch threads | 8~56T.P.l |
| Tailstock quill diameter | Ø30mm |
| Tailstock quill travel | 65mm |
| Taper of tailstock quill | MT2 |
| Motor power | 750w |
| Voltage | 110V~240V(1PH) |
| Packing size | 1400x690x570mm |
