BTL460 CNC Lathe with Bar Feeder
The BTL460 is a precision CNC lathe designed for continuous, automated production. Equipped with a bar feeder, it delivers efficient, unattended machining of bar stock, making it ideal for high-volume manufacturing of small to medium-sized parts.
Key Features
- Integrated bar feeder for automated material loading
- Spindle bore of Ø66 mm or Ø80 mm (optional)
- Maximum turning diameter of Ø400 mm
- Swing over cross slide of Ø240 mm
- Distance between centers: 750 mm or 1000 mm (optional)
- Spindle speed range: 30–2500 rpm
- Rigid bed width of 330 mm for stable cutting
- A2-6 spindle nose with MT6 taper
Specifications
| Model | BTL460 |
|---|---|
| Turning diameter (Max.) | Ø400 mm |
| Swing over cross slide | Ø240 mm |
| Distance between centers | 750 / 1000 mm (Optional) |
| Center height | 200 mm |
| Width of bed | 330 mm |
| Spindle nose | A2-6 |
| Spindle bore | Ø66 / 80 mm (Optional) |
| Taper of spindle bore | MT6 |
| Range of spindle speed | 30–2500 rpm |
Applications
The BTL460 with bar feeder is suitable for a wide range of industries, including automotive, aerospace, electronics, and general machining. It excels in producing shafts, bushings, fittings, and other turned parts from bar stock.
Why Choose the BTL460?
Combining a robust construction with automated bar feeding, the BTL460 reduces manual intervention, increases productivity, and ensures consistent part quality. Its optional spindle bore and center distance configurations allow customization to match specific production requirements.
For more information or to discuss your specific needs, please contact Jiangsu Bestech Industrial Co., Ltd.
What is with bar feeder BTL460 60mm spindle bore CNC lathe machine?
The BTL460 is a CNC lathe machine equipped with a bar feeder, designed for continuous machining of bar stock. It features a 60mm spindle bore (optional Ø66/80mm), a maximum turning diameter of Ø400mm, and a swing over cross slide of Ø240mm. Manufactured by Jiangsu Bestech Industrial Co., Ltd., this machine is suitable for high-volume production of precision turned parts.
Applications
- Mass production of small to medium-sized turned parts from bar stock
- Automotive components such as shafts, pins, and fittings
- Hydraulic and pneumatic parts manufacturing
- General precision machining in metalworking industries
- Production of fasteners and connectors
FAQ
What is the spindle bore of the BTL460 CNC lathe?
The BTL460 has a standard spindle bore of 60mm, with optional Ø66mm or Ø80mm available.
What is the maximum turning diameter of this machine?
The maximum turning diameter is Ø400mm.
Does the BTL460 include a bar feeder?
Yes, the BTL460 is equipped with a bar feeder for continuous bar stock machining.
What is the swing over cross slide?
The swing over cross slide is Ø240mm.
Who is the manufacturer of the BTL460?
The BTL460 is manufactured by Jiangsu Bestech Industrial Co., Ltd.
