Description
| Turning diameter (Max.) | Ø200mm |
| Swing over cross slide | Ø115mm |
| Distance between centers | 350mm/520mm (Optional) |
| Width of bed | 125mm |
| Spindle bore | Ø20mm |
| Spindle taper | MT3 |
| Spindle speed (6 steps) | 140~1710rpm |
| Top slide travel | 78mm |
| Cross slide travel | 119mm |
| Max. section of tools | 10x10mm |
| Range of metric threads | 0.4~3mm |
| Range of inch threads | 8~32 T.P.l |
| Tailstock quill diameter | Ø22mm |
| Tailstock quill travel | 35mm |
| Taper of tailstock quill | MT2 |
| Motor power | 550w |
| Voltage | 110V~240V(1PH) |
| Packing size | 1050x570x570mm |
