For metal working Z3050 X 16 / 1 radial arm drilling machine

Max.drilling capacity:50mm

Spindle travel:315mm

Spindle taper:Morse No. 5#

Number of spindle speeds:16 step

Model	Z3050X16/1
Max. Drilling diameter	50mm
Distance between spindle axis and column	350-1600mm
Distance spindle nose and working surfance of base	320-1220mm
Distance of headstock horizontal movement	1250mm
Spindle travel	315mm
Ramge of spindle speeds	25-2000rpm
Number of spindle speeds	16 (steps)
Range of spindle feeds	0.04-3.20mm/r
Table size	630x500x500mm
Spindle motor power	4kw
Gross weight	3500kg
Packing size	2500x1070x2840mm

For metal working Z3080 X 25 / 1 RAM milling machine
